How to prevent cabinet doors and draws from opening ???

Lee Bradley · July 25, 2012, 11:21:21 AM

My wife has very bad Rheumatoid Arthritis and so did not want cabinets that were hard to open and I wanted cabinets that would not rattle going down the road. Our solution was a quarter-turn, compression latch; the first quarter turn turns the latch into the closed position and the second quarter turn pulls the latch in a 1/4". These are available at http://www.steelcitysupply.com/c-2620-emka-standard-quarter-turns.aspx , I used the 1022-U85 with 1022-49 latch these are not easy to find on the web site. I suggest calling and talking to Dana.

Oonrahnjay · July 25, 2012, 12:00:41 PM

Ed and others. Thank you, these are exactly what I've spent far too much time looking for on Google and couldn't find (wrong name, I expect). Really appreciate it. BH

Ed Hackenbruch · July 25, 2012, 02:10:31 PM

I think i got and used 16 of them, kind of wish i had gotten 3-4 extra as i found that i could have used 2 or 3 more for other things.....

Jriddle · July 25, 2012, 06:54:14 PM

I went to the big box store and bought child latches and the work great. The drawers and doors will open a inch or so but don't fly open.

John

Just A Newell · July 26, 2012, 08:04:20 PM

This is the latch that Newell used in the 80's. You can adjust the tension with the screws top and bottom.

Dave Siegel · July 27, 2012, 06:56:49 AM

We used these latches but got them from a local kitchen cabinet supply house for $7 each. I have one on every door and drawer in the bus.

http://www.rockler.com/product.cfm?page=1376&site=ROCKLER

P.S. I also made my upper cabinet doors swing up and they stay up with a bar top stay while open. This way they will never open while on the road and are completely out of the way while open.

Dave

eagle19952 · July 27, 2012, 12:49:38 PM

I have a whole (dozens) bunch of this type:(lower right corner ones cept mine the actuator buttons are square not rounded).

And in certain places the "Newell" type never had a failure....now the referidgerator..that gets a double bungeee....it can make a horrble mess...

Ed Hackenbruch · July 27, 2012, 02:46:05 PM

I have two small doors that have the Newell type on them, never looked at them that close, never knew you could adjust them.

Oonrahnjay · July 27, 2012, 03:20:32 PM

Quote from: eagle19952 on July 27, 2012, 12:49:38 PMI have a whole (dozens) bunch of this type:(lower right corner ones cept mine the actuator buttons are square not rounded).

What was your source for buying these (or brand name)? Thanks, BH NC USA

akbusguy2000 · July 27, 2012, 03:34:10 PM

I tried several different type before settling on these:

http://www.allegiscorp.com/DisplayPartAction.do?partId=21771&groupId=557&groupElementId=1&displayTemplate=/jsp/displayDetailTemp_15.jsp&cat=Single-Point+Slam+Latches

They work perfectly and hold well, and they are invisible. Look around their site - they have every imaginable latch and you may find some to your liking:

http://www.allegiscorp.com/jsp/products.jsp?cat=all

tg

robertglines1 · July 27, 2012, 04:13:48 PM

Bottom of draws glue a small wood wedge that just catches inside of cabinet cross bar. you must lift up about 1/8 inch to open drawer. when you push in the wedge rides up over cross piece. It has worked on several coaches for 20 plus years. Yes on doors mechanical ones are better. My new build came with self closing hardware that holds draws and doors firm until you pull hard on them. Bob
